400T/500/630T/800T Gantry Shear Hydraulic Steel Scrap Metal Shear For Cutting

400T/500/630T/800T Heavy Duty Gantry Shear Hydraulic Steel Scrap Metal Shear for Cutting

Products Description

Gantry shearing machine is a kind of equipment suitable for heavy scrap cutting processing, used for thin steel material, steel bar, steel plate, nickel plate, steel plate, round steel, steel pipe, scrap copper, scrap iron, light metal structural parts, stainless steel, metal pressing block, metal pressing block and other scrap metal cold cutting short, processing into qualified charge.

Product Parameters

Model	Shear force(tons)	Processing capacity(t/h)	Length of knife edge(mm)	Shear frequency(per/min/sub)	Power(kw)
XSM-315	315	3-5	1200	2-4	22*2
XSM-400	400	4-7	1400	2-4	37*2
XSM-500	500	5-8	1500	2-4	45*2
XSM-630	630	8-10	1600	2-4	45*3
XSM-800	800	12-15	1800	2-4	55*3
XSM-1000	1000	15-20	2000	2-4	55*4
XSM-1250	1250	20-30	2000	2-4	55*4
We can customize the product on your request, please send inquiry to contact us

Product Details

1,Through automatic feeding box,after the material is grabbed to the upper material box, the waste is automatically sent to the cutting edge by the conveyor belt, and the feeding speed can be adjusted by the speed regulating motor.

2,The two sides of the material box are equipped with side extrusion oil cylinders. If the large-scale waste materials, such as scrapped cars, cannot pass the cutting edge of the gantry shear, they can be squeezed and reduced by the side extrusion oil cylinder, and then sent to the cutting edge through the conveyor to cut off.

400T/500/630T/800T Gantry Shear Hydraulic Steel Scrap Metal Shear For Cutting

Product Features

1,Gantry shearing machine adopts hydraulic transmission, compared with mechanical transmission shearing machine, with small volume, light weight, small inertia, low noise, smooth action, easy to operate, flexible, large shear section, scissors mouth adjustment and other advantages, safe operation and use, easy to achieve overload protection.

2,Gantry shearing machine has manual, automatic, remote control function, convenient and simple operation control, scissors mouth in the working process of any position to start cutting and stop, and can be cut according to the size of the material, arbitrary control of the size of the cutting mouth, in order to obtain economic benefits.

3,Gantry shear designed fast type, without increasing the motor power and oil pump displacement condition, in (about 4001600 tons) shear speed to maintain fast, shear large material will automatically convert speed. The original shear force is restored and the working efficiency is nearly doubled.

4,Gantry shear machine with fast device. Without increasing the motor power and oil pump displacement, a fast loop is designed to increase the cutting speed from 8 times per minute to 12 times per minute (refers to The Times when the scissors open), and improve the efficiency of nearly double. This function is unique in the national peer.

Product Application

Applicable Materials

Thin steel material, steel bar, steel plate, nickel plate, steel plate, round steel, steel pipe, scrap copper, scrap iron, light metal structural parts,stainless steel, metal pressing block, automobile body, aluminum alloy, copper, iron filings, steel wire, metal pressing block and other scrap metal cold cutting short
