Metal Recycling Machine Car Body Metal Crusher Aluminum Cans Scrap Crusher

Product Categories

Henan Xrido Environmetal Protection Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Metal Recycling Machine Car Body Metal Crusher Aluminum Cans Scrap Crusher

Ask Lasest Price
Brand Name :	Xrido
Model Number :	Customizable
Certification :	CE ISO
Payment Terms :	Negotiable
Delivery Time :	2-32 work days

Add to Cart

Product Details
Company Profile

Metal Recycling Machine Car Body Metal Crusher Aluminum Cans Scrap Crusher

Scrap Metal Recycling Machine Car Body Metal Crusher Aluminum Cans Scrap Crusher Mixed Metal Crusher Machine

Products Description

Scrap steel crusher is a kind of mechanical equipment specially used for processing scrap metal, mainly used for the crushing and processing of scrapped cars, scrapped home appliances and light and thin scrap steel. Its core function is to crush metal materials such as scrap steel and scrap iron into particles or blocks of uniform specifications through mechanical force, which is convenient for subsequent sorting, transportation and recycling.

Metal Recycling Machine Car Body Metal Crusher Aluminum Cans Scrap Crusher

Applicable materials for scrap steel/aluminum/iron crushers:

Scrap steel: automobile shells, color steel tiles, steel bars, industrial scrap steel.

Scrap aluminum: aluminum alloy doors and windows, cans, aluminum home appliance parts.

Scrap iron: iron barrels, mechanical parts, construction waste.

Composite materials: metal-containing cables and circuit boards (pretreatment required).

Metal Recycling Machine Car Body Metal Crusher Aluminum Cans Scrap Crusher

Product Paramenters

model	voltage	accessory equipment	power(kw)	capacity(t/h)
PSJ-140	380v	Feeding conveyor one Discharging conveyor one Iron conveyor one Impurity conveyor one Magnetic separation system one Dust removal system one Control system one Intelligent Visual System (Optional) one Sprinkler system (optional) one	132	2-3
PSJ-200	380v		200	3-5
PSJ-280	380v		280	4-7
PSJ-315	380v		315	5-8
PSJ-450	380v		450	8-12
PSJ-630	10kv		630	10-15
PSJ-750	10kv		750	12-17
PSJ-800	10kv		800	15-20
PSJ-900	10kv		900	20-30
1500HP	10kv		1200	25-40
2000HP	10kv		1500	50-60
3000HP	10kv		2250	60-80
4000HP	10kv		3000	80-100
6000HP	10kv		4420	100-160
8000HP	10kv		6000	160-200
10000HP	10kv		7500	200-26

*This is the basic model of our scrap crusher machine. Our factory manufactures customized machines according to the different requirements of different customers.

Working principle
The scrap steel crusher hits the scrap steel material with a high-speed rotating hammer, tearing and squeezing it into crushed materials of uniform specifications. The crushed scrap steel has the characteristics of neat material shape, high bulk density, few attachments and high purity.

Core components
Crushing host: high manganese cast steel lining is adopted, which has strong wear resistance.
Sorting system: including magnetic separator, vibrating screen, etc., used to separate metal and non-metallic impurities.
Conveying system: such as belt conveyor and scale plate conveyor, to realize automatic feeding and discharging.
Dust removal system: reduce dust pollution during crushing process.

Key equipment of metal crushing and recycling production line:

Industrial Scrap Metal Double Shaft Shredding Machine Metal Crusher 6

Industrial Scrap Metal Double Shaft Shredding Machine Metal Crusher 7

Other Metal Recycling Machine

Reliable and durable recycling technologies for material separation and recovery,treatment of various types of solid waste and metal scrap. Metal recycling can benefit your Enhance and economic value , Help you improve recycling eliminate landfilling of waste.

With XRIDO’s ready-to-use spare parts library , you gain peace of mind through seamless maintenance and reduced downtime.

Process flow of scrap steel/aluminum/iron crushers recycling line:

Pretreatment: remove non-metallic attachments such as liquids and plastics from metal materials.

Crushing: the material enters the crushing chamber and is crushed at high speed by a hammer or a cutter disc.

Sorting: magnetic separation of ferrous metals, eddy current separation of non-ferrous metals (such as aluminum and copper).
Discharge: Pure metal crushed materials are transported to the baler or shipped directly.


Scrap Metal Shredder Sorting Line	Waste Aluminum Crushing Production Line

Water Radiator Crushing Sorting Line	UBC Aluminum Cans Decoating Machine

Successful Project

Industrial Scrap Metal Double Shaft Shredding Machine Metal Crusher 16

Industrial Scrap Metal Double Shaft Shredding Machine Metal Crusher 17
