    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Ask Lasest Price
    Brand Name : Xrido
    Model Number : Customizable
    Certification : CE ISO TUV
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram,Negotiable
    Delivery Time : 2-30 Working Days
    • Product Details
    • Company Profile

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine
    Products Description
    Eddy current separator for scrap steel crushing material is a device that uses the eddy current principle to separate metal and non-metal from scrap steel tailings. The working principle of eddy current separator is based on the difference in electrical conductivity of materials. When conductive non-ferrous metals (such as copper, aluminum, etc.) pass through a high-frequency alternating strong magnetic field, eddy currents will be induced inside the metal. This eddy current itself will generate a magnetic field in the opposite direction of the original magnetic field, so that the non-ferrous metals are repelled by the magnetic field and leap forward along the conveying direction to achieve separation from other non-metallic materials.

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Main components of eddy current separator for scrap steel crusher:
    Eddy current separator for scrap steel crusher is mainly composed of permanent magnetic roller, material conveying system (including material conveyor belt, conveyor belt drive roller and reduction motor), etc. Some equipment may also include vibrating feeder, control power supply and other parts.

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Product Paramenters
    Belt width(mm)
    Effective Space(mm)
    Separate Motor(kw)
    Belt Driven Motor (KW)
    Shaking Table Motor(kw)
    Small Material (m3/h)
    Big
    Material (m3/h)
    450
    320
    3
    0.55
    120
    3
    6
    580
    420
    3
    0.55
    120
    4
    8
    650
    520
    4
    0.75
    120
    5
    10
    800
    620
    5.5
    0.75
    120
    7
    14
    1000
    820
    5.5
    1.1
    2*120
    9
    18
    1200
    1050
    7.5
    1.1
    2*120
    11
    22
    1500
    1350
    7.5
    1.1
    2*120
    14
    28
    Application scope
    The eddy current separator for scrap steel crushing is widely used to recover copper, aluminum and other non-ferrous metals from the crushed slices of various industrial solid wastes (such as electronic waste, waste plastic doors and windows, waste cars, etc.). It can greatly improve production efficiency, reduce the labor intensity of workers, and the sorting effect can reach more than 98%.
    ● Scrap steel crushing plant: sort non-ferrous metals from scrap steel crushing tailings.
    ● Automobile dismantling and crushing plant: sort non-ferrous metals from crushed materials.
    ● Electronic circuit board recycling plant: recover non-ferrous metals from scrap electronic circuit fragments.
    ● Glass recycling industry: remove aluminum bottle caps and aluminum or copper alloy parts from broken glass materials.
    ● Pre-sorting and processing of domestic waste: sort aluminum cans, bottle caps and copper and aluminum alloy parts from domestic waste.
    ● Waste paper recycling industry: sort non-ferrous metals from papermaking residues.

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Technical features
    ● Easy to operate, can realize the automatic separation of non-ferrous metals and non-metals.
    ● Easy to install, can be effectively connected with new or existing production lines.
    ● The magnetic system of the strong magnetic field eddy current separator adopts an eccentric design, and the magnetic field strength is as high as 3000-3500Gs, which increases the recovery rate of non-ferrous metals by more than 10%.
    ● Simple and flexible adjustment, good sorting effect.
    ● Low energy consumption, energy saving and environmental protection.
    Customer Site
    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Non Ferrous Sorting Recycling Machines Nonferrous Metals Separation Machine Scrap Steel Crushing Material Separator Machine

    Eddy current separator maintenance instructions
    1. Check and tidy up in time. Clean the machine at the end of each day. Check whether the screws of each part are loose or there
    are worn parts, such as claws and screens.
    2. Fill with grease, usually install the cap oil cup on the bearing. Under normal circumstances, as long as the oil cup cover
    rotates 1 / 4 turn every 2 hours, the grease in the cup can be pressed into the bearing. For closed bearings, grease can be added
    every 300 hours. After long-term use, if the grease is replaced, clean the bearing and replace with new grease. When the equipment
    is working, the temperature of the bearing shall not exceed 40 ° C. If the bearing temperature continues to rise under normal
    operating conditions, the cause should be found and the fault resolved.
    3. Carefully clean the material to be damaged. It is forbidden to mix copper, iron, lead and other metal parts, large stones and
    other sundries into the damage room.
